A520M K V2 GIGABYTE

Name: A520M K V2 GIGABYTE
SKU: 9MA52MK2-00-G11
Price: 54.00 EUR
Availability: InStock

Próxima llegada:
Almacén: Almacen A

Part number: 9MA52MK2-00-G11
EAN/UPC: 4719331852771

La disponibilidad muestra el stock en nuestros almacenes, no en la tienda física. Si el producto está disponible, puede decidir que se lo enviemos a su domicilio o solicitar la recogida en tienda.

Fabricante: Gigabyte

Puerto USB: 2 x USB 2.0 + 4 x USB 3.x

Salidas: HDMI, VGA

Tamaño: ATX

Socket: AM4

Tipo RAM: DDR4

RAM máxima: 64 GB

PCIe: PCIe 3.0

LAN: 1 Gbit

Chipset: A520

Ranuras RAM: 2

M.2: 1 x M.2

SATA: 4 x SATA

USB internos: 2 x USB 2.0 + 1 x USB 3.x

Disponibilidad:

Hay existencias

54.00€

Hay existencias

Descripción

Especificaciones Técnicas
Modelo	PLACA BASE A520M K V2 GIGABYTE
Part Number	9MA52MK2-00-G11
Procesador	– AMD Socket AM4, support for: AMD Ryzen 5000 G-Series Processors/ AMD Ryzen 5000 Series Processors/ AMD Ryzen 4000 G-Series Processors/ AMD Ryzen 3000 Series Processors – (Please refer ”CPU Support List” for more information.)
Chipset	AMD A520
Memoria	– 2 x DDR4 DIMM sockets supporting up to 64 GB (32 GB single DIMM capacity) of system memory – Support for DDR4 5100(O.C.) / 4800(O.C.) / 4600(O.C.) / 4400(O.C.) / 4266(O.C.) / 4133(O.C.) / 4000(O.C.) / 3866(O.C.) / 3733(O.C.) / 3600(O.C.) / 3466(O.C) / 3400(O.C.) / 3200 / 2933 / 2667 / 2400 / 2133 MHz memory modules – Dual channel memory architecture – Support for ECC Un-buffered DIMM 1Rx8/2Rx8 memory modules (operate in non-ECC mode) – Support for non-ECC Un-buffered DIMM 1Rx8/2Rx8/1Rx16 memory modules – Support for Extreme Memory Profile (XMP) memory modules – (Please refer ”Memory Support List” for more information.)
Gráfica Integrada	– Integrated Graphics Processor: – 1 x HDMI port, supporting a maximum resolution of 4096×2160@60 Hz – Support for HDMI 2.1 version, HDCP 2.3, and HDR
Maximum shared memory of 16 GB	Audio
LAN	Realtek GbE LAN chip (1 Gbps/100 Mbps)
Zócalos de Expansión	– CPU: – 1 x PCI Express x16 slot, supporting PCIe 3.0 and running at x16 – Chipset: – 1 x PCI Express x1 slot, supporting PCIe 3.0 and running at x1
Interfaz de almacenamiento	– CPU: – 1 x M.2 connector (Socket 3, M key, type 2280 SATA and PCIe 3.0 x4/x2 SSD support) – Chipset: – 4 x SATA 6Gb/s connectors – Support for RAID 0, RAID 1, and RAID 10
USB	– CPU: – 4 x USB 3.2 Gen 1 ports on the back panel – Chipset: – 2 x USB 3.2 Gen 1 ports available through the internal USB header – 6 x USB 2.0/1.1 ports (2 ports on the back panel, 4 ports available through the internal USB headers)
Conectores Internos E/S	– 1 x 24-pin ATX main power connector – 1 x 8-pin ATX 12V power connector – 1 x CPU fan header – 1 x system fan header – 1 x M.2 Socket 3 connector – 4 x SATA 6Gb/s connectors – 1 x front panel header – 1 x front panel audio header – 1 x USB 3.2 Gen 1 header – 2 x USB 2.0/1.1 headers – 1 x Trusted Platform Module (TPM) header (2×6 pin, for the GC-TPM2.0_S module only) – 1 x speaker header – 1 x Clear CMOS jumper – 1 x chassis intrusion header
Panel E/S Trasero	– 1 x PS/2 keyboard/mouse port – 1 x HDMI port – 4 x USB 3.2 Gen 1 ports – 2 x USB 2.0/1.1 ports – 1 x RJ-45 port – 3 x audio jacks
Controlador E/S	iTE I/O Controller Chip
BIOS	– 1 x 128 Mbit flash – Use of licensed AMI UEFI BIOS – PnP 1.0a, DMI 2.7, WfM 2.0, SM BIOS 2.7, ACPI 5.0
Formato	Micro ATX Form Factor; 23.3cm x 19.8cm

Part Number: 9MA52MK2-00-G11
EAN: 4719331852771

SKU: 9MA52MK2-00-G11 Categorías: Componentes, Placa base AMD, Socket AM4 Etiqueta: Almacen A
