ASUS PRIME B860-PLUS-CSM ATX 1851

Name: ASUS PRIME B860-PLUS-CSM ATX 1851
SKU: 90MB1KA0-M0EAYC
Price: 179.00 EUR
Availability: InStock

Próxima llegada:
Almacén: Almacen Y

Part number: 90MB1KA0-M0EAYC
EAN/UPC: 4711387814857

La disponibilidad muestra el stock en nuestros almacenes, no en la tienda física. Si el producto está disponible, puede decidir que se lo enviemos a su domicilio o solicitar la recogida en tienda.

Fabricante: Asus

Puerto USB: 2 x USB 2.0 + 3 x USB 3.x + 1 x USB C

Salidas: Displayport, DVI, HDMI

Tamaño: ATX

Iluminación: RGB

Socket: LGA 1851

Generación CPU: Generación 15

Tipo RAM: DDR5

RAM máxima: 256 GB

Velocidad RAM: 8666 Mhz

PCIe: PCIe 5.0

LAN: 2.5 Gbit

Bluetooth: Bluetooth

Chipset: B860

Ranuras RAM: 4

M.2: 3 x M.2

SATA: 4 x SATA

USB internos: 2 x USB 2.0 + 2 x USB 3.x

Disponibilidad:

Solo quedan 2 disponibles

179.00€

Solo quedan 2 disponibles

Descripción

Especificaciones Técnicas
Modelo	PLACA BASE PRIME B860-PLUS-CSM ASUS
Part Number	90MB1KA0-M0EAYC
CPU	Support Intel Core Ultra Processors (Series 2) , LGA1851 Supports Intel Turbo Boost Technology 2.0 and Intel Turbo Boost Max Technology 3.0** * Refer to https://www.asus.com/support/download-center/ for CPU support list * Intel Turbo Boost Max Technology 3.0 support depends on the CPU types
Memory	4 x DIMM slots, max 256GB, DDR5 Support up to 8666+MT/s (OC), Non-ECC, Un-buffered ,Clocked Unbuffered DIMM (CUDIMM)* Dual channel memory architecture DIMM Fit Supports Intel Extreme Memory Profile (XMP) memory module ASUS Enhanced Memory Profile III (AEMP III) * Supported memory types, data rate (speed), and number of DRAM modules vary depending on the CPU and memory configuration, for more information please refer to CPU/Memory Support list under the Support tab of product information site or visit https://www.asus.com/support/download-center/ Adjustments will be made based on the specifications of mass-produced memory products available on the market * Non-ECC, un-buffered DDR5 memory supports On-Die ECC function
Graphics	1 x DisplayPort 1 x HDMI port* * Graphics specifications may vary between CPU types Please refer to www.intel.com for any updates * Supports max 4K@60Hz as specified in DisplayPort 1.4 * Supports 4K@60Hz as specified in HDMI 2.1 *** VGA resolution support depends on processors’ or graphic cards’ resolution
Expansion Slots	Intel Core Ultra Processors (Series 2)* 1 x PCIe 5.0 x16 slot (PCIEX16(G5)) Intel B860 Chipset 1 x PCIe 4.0 x16 slot (PCIEX16(G4)_3) (supports x4 mode) 3 x PCIe 4.0 x16 slots (PCIEX16(G4)_1/2/4) (support x1 mode) To ensure compatibility of the device installed, please refer to https://www.asus.com/support/download-center/ for the list of supported peripherals
Storage	Total supports 2 x M.2 slots and 4 x SATA 6Gb/s ports* Intel Core Ultra Processors (Series 2)* M.2_1 slot (Key M), type 2242/2260/2280 (supports PCIe 5.0 x4 mode) Intel B860 Chipset M.2_2 slot (Key M), type 2242/2260/2280/22110 (supports PCIe 4.0 x4 mode) 4 x SATA 6Gb/s ports * Intel Rapid Storage Technology supports SATA RAID 0/1/5/10
Ethernet	1 x Realtek 2.5Gb Ethernet ASUS LANGuard
USB	Rear USB (Total 6 ports) 1 x USB 20Gbps port (1 x USB Type-C) 2 x USB 10Gbps ports (2 x Type-A) 1 x USB 5Gbps port (1 x Type-A) 2x USB 2.0 ports (2 x Type-A) Front USB (Total 7 ports) 1 x USB 5Gbps port (1 x USB Type-C) 1 x USB 5Gbps header supports additional 2 USB 5Gbps ports 2 x USB 2.0 headers support 4 additional USB 2.0 ports
Audio	Realtek 7.1 Surround Sound High Definition Audio CODEC* Supports: Jack-detection, Multi-streaming, Front Panel Jack-retasking Supports up to 24-Bit/192 kHz playback Audio Features Audio Shielding Premium audio capacitors Dedicated audio PCB layers * A chassis with an HD audio module in the front panel is required to support 7.1 Surround Sound audio output
Back Panel I/O Ports	1 x USB 20Gbps port (1 x USB Type-C) 2 x USB 10Gbps ports (2 x Type-A) 1 x USB 5Gbps port (1 x Type-A) 2 x USB 2.0 ports (2 x Type-A) 1 x DisplayPort 1 x HDMI port 1 x Realtek 2.5Gb Ethernet port 3 x Audio jacks
Internal I/O Connectors	Fan and Cooling related 1 x 4-pin CPU Fan header 1 x 4-pin CPU OPT Fan header 1 x 4-pin AIO Pump header 4 x 4-pin Chassis Fan headers Power related 1 x 24-pin Main Power connector 1 x 8-pin +12V CPU Power connector Storage related 3 x M.2 slots (Key M) 4 x SATA 6Gb/s ports USB 1 x USB 5Gbps connector (supports USB Type-C) 1 x USB 5Gbps header supports 2 additional USB 5Gbps ports 2 x USB 2.0 header support 4 additional USB 2.0 ports Miscellaneous 3 x Addressable Gen 2 headers 1 x Aura RGB header 1 x Clear CMOS header 1 x Chassis Intrusion header 1 x COM Port header 1 x Front Panel Audio header (F_AUDIO) 1 x S/PDIF Out header 1 x SPI TPM header (14-1pin) 1 x 10-1 pin Front System Panel header 1 x Thunderbolt (USB4) header
BIOS	2 x 128 Mb Flash ROM, UEFI AMI BIOS
Form Factor	ATX Form Factor 12 inch x 9.6 inch ( 30.5 cm x 24.4 cm )

Part Number: 90MB1KA0-M0EAYC
EAN: 4711387814857

SKU: 90MB1KA0-M0EAYC Categorías: Componentes, Placa base Intel, Socket 1851 Etiqueta: Almacen Y
